Butterfly valve for actuator mounting (ISO)

² Size: DN50~DN300 (2"~12")

² Working pressure:

² DN50~DN150  (2"-6") 0.6MPA (100psi)

² DN200~DN300 (8"~12") 0.4MPA (60psi)

² Material: PVC,CPVC,PPG/FRPP,PPH,PP-R,ABS,PE

² Seal:EPDM

² Standard:GB,DIN,ANSI,JIS,

Advantage:

² Economical Alternative to Metal Butterfly Valves,

² Unique design,Corrosion resistance,Low torque,

² High strength,extremely long life

² Disk design with reinforced rib,to ensure the safety of pipe system.

² Exposed mounting pad,easy to install or replace actuator of electric actuator or pneumatic actuator.

² ISO 5211 Mounting Pad

Application:

² Different water system including waste water system

² Chemical processing/Marine or Corrosive environments

² Irrigation/Aquarium/Pool/or more
